Optrel Crystal 2.0 Welding Helmet
You won’t believe your eyes
- Crystal Lens Technology
- Brightness level 2.0
- Shade levels 4 to 12
True colour vision directly when welding
For the first time in the history of welding you as a welder see the joining process as it actually takes place. How the weld pool melts, how the weld seam is created. You can see how the filler material is immersed in the welding pool and gain complete control over your work.
CLT offers you brilliant vision, like through a window pane. Crystal clear. And thanks to optrel Autopilot always with the right protection level.
True colour means not the same as true colour
As far as always the distinction can be seen upon taking a closer look. With the crystal lens technology you will recognize the difference immediately when putting it on.
The color perception in light state is almost like looking through clear window glass and in dark mode you enjoy a detailled and high-contrast view of the welding pool with a never-seen-before clearness.
You won’t believe your eyes
With light transmission of 31% in bright condition (protection level 2!) welders have for the first time a practically unclouded and clear view of their working environment. This in combination with the almost perfect colour spectrum of the CLT2.0 for the first time allows welders to see what is really going on in the weld pool, and with a clarity that equates to insights into a new dimension. This is why welders describe this as an enlightenment.
- Crystal Lens Technology 2.0
- Autopilot / Shade Level 4-12
- Hard Hat Adapter
- Sensitivity Adjustment
- Twilight Function
- Comfort Headband
- Lightweight
- Patented Excenter
- Grind Mode
- Outside Adjustment
- True Color View
- Warranty Extension: 2+1 Years
Technical Data
- Shade levels: inactive: shade level 2.0 / active, manual: shade level 4-12
- Autopilot: Automatic protection level regulation across a range from 4-12 with individual calibration option of ± 2
- Power supply: Solar cells, 2 lithium batteries (CR2032)
- Sensors: Three Sensors
- Sensitivity: Infinitely adjustable, now with super high sensitivity
- Switching time: bright to dark: 0.100 ms at room temperature at 55°C / 0.070 ms at 55°C / dark to bright: 0.1 s to 2.0 s (with dimming function)
- EN379 classification: Optical class: 1 / Scattered light: 1 / Homogeneity: 1 / Angular dependence: 2
- Shape stability: Welding mask: up to 220°C / 428°F / Front cover lens: up to 137°C / 279°F
- Eye protection Ultraviolet / Infrared Protection: maximum protection at any shade level
- Operating temperature: -10°C to + 70°C / 14°F to 158°F
- Storage temperature: -20°C to + 80°C / -4°F to 176°F
- Weight: 460 g / 18,7 oz
- Scope of delivery: Welding helmet, manual
- Warranty: 2 years / 1 year warranty extension (except batteries) for online product registration within the first 6 months.
Fields of Application
- Electrode Welding (Stick Welding, ARC, SMAW)
- MIG/MAG (GMAW)
- GMAW High melting rate process
- Flux Cored Wire Welding
- TIG Welding (GTAW)
- Plasma Arc Welding
- Micro Plasma Arc Welding
- Plasma Cutting
- Gas Welding
- Grind Mode
What’s In The Box?
Delivered with all lenses, batteries and parts required for immediate operation. A full spares list is available for replacement parts.
Curious?
We are the approved Southwest distributor for all Optrel products, and hold a range of helmets in stock. If you would like to try one on, come and visit our showroom.
